- 您现在的位置：买卖IC网 > Sheet目录122 > BAS86,115 (NXP Semiconductors)DIODE SCHOTTKY 50V 200MA SOD80C
       NXP Semiconductors BAS86 Schottky barrier single diode BAS86 All information provided in this document is subject to legal disclaimers. ? NXP B.V. 2012. All rights reserved Product data sheet 25 July 2012 5 / 9 trr (1) + IF t output signal tr tp t 10 % 90 % VR input signal V = VR +IF ×RS RS = 50 Ω IF D.U.T. Ri = 50 Ω SAMPLING OSCILLOSCOPE mga881 (1) IR = 1 mA Fig. 5. Reverse recovery time test circuit and waveforms 9. Package outline 06-03-16 Dimensions in mm 1.60 1.45 0.3 3.7 3.3 0.3 Fig. 6. LLDS; MiniMelf (SOD80C) 10. Soldering sod080c 2.30 4.30 4.55 0 1.60 5 1.7 2.2 0.90 (2x) solder lands solder resist occupied area solder paste Dimensions in mm Fig. 7. Reflow soldering footprint for SOD80C (LLDS; MiniMelf) |
